YOKOGAWA ANB10D-425/CU2T
Yokogawa ANB10D-425/CU2T module
Product name: Yokogawa ESB Bus node unit
The ANB10D-425/CU2T is an ESB bus node unit produced by YOKOGAWA, Japan. The Extended System Bus (ESB) is Yokogawa’s own fieldbus used to connect various I/O modules for distributed control.
Product description
As a node on the ESB bus, this module is responsible for the following functions:
I/O signal acquisition and conversion: the field analog and digital sig
nals are converted into standard digital signals, and transmitted to the host computer through the ESB bus.
Power supply: Provides power for the I/O modules connected to the node.
Communication with the host computer: Communicate with the host computer (such as CENTUM VP) through the ESB bus to achieve data exchange and control.
Main feature
Dual redundant ESB bus: Improves system reliability and prevents single points of failure.
Modular design: easy to expand and maintain.
Supports a variety of I/O modules: Various types of analog and digital I/O modules can be connected.
High reliability: suitable for harsh industrial environments
Parameter Name Parameter Value Unit description
Input voltage 24V DC Power supply voltage
Output current The output current that A supplies to the I/O module depends on the connected I/O module
Communication Protocol Protocol Used by the ESB to communicate with the host
Operating temperature -20 ° C to +60 ° C Operating temperature range
Relative humidity 5% to 95% % Operating humidity range
