Woodward 2301E
The Woodward 2301E module is a high-performance automation control module designed to automate the control of generators or other mechanical equipment. It is often used as a core component in engine control and automation systems, responsible for monitoring and adjusting the operating status of the engine to ensure its normal operation. The module is equipped with multiple digital input and output channels that can be connected to sensors, actuators and other devices for signal acquisition and control operations. In addition, it also has a variety of communication interfaces, such as serial port, Ethernet, Modbus, etc., to facilitate
data exchange and communication with other system components and superior control systems. Woodward 2301E modules are usually programmable, and users can write and load control programs according to specific application requirements. At the same time, it can also provide real-time data, real-time monitoring and feedback on engine operating parameters, with fault detection and alarm functions, as well as engine protection functions, to ensure the stable operation of the system.
Product parameters:
Compatibility: Backward compatible with existing 2301D products, with the same footprint and mounting configurating3.
Serial ports: There are separate RS-232 and RS-422 serial ports, both with 9-pin connector 3.
Status LED: An additional status LED that includes the power supply and RS-422 communication to indicate the status of the module 3.
Fault data logging: 16 seconds of data are collected every 10 milliseconds during downtime, peak speed, and load detection events.3
Output: Low current PWM output for driving Woodward L Series, F Series, P Series and PISC actuator 3.
Power strip: The new power strip can accommodate additional I/O, giving users more expandability 3.
Specifications:
Functions: engine control, digital input/output, communication interface, programmability, real-time monitoring, fault detection and alarm, engine protection, data logging and historical data analysis, etc.
Working environment: suitable for common and dangerous places3.
Power Supply: 24 volts DC power supply 3.
