WESTINGHOUSE 5X00225G01
The 5X00225G01 is part of the WESTINGHOUSE Ovation Distributed Control System (DCS) for controlling high speed analog output signals from external devices. It has 4 channels, each of which can be configured for a different analog output type, such as current, voltage, etc. The module has a response time of less than 100 microseconds and is suitable for applications that require fast control, such as servo systems, robot control, etc.
Product parameters:
Model: 5X00225G01
Brand: WESTINGHOUSE
Series: Ovation
Type: High speed analog output module
Number of channels: 4 channels
Output type: The following types can be configured:
Current: 4mA to 20mA
Voltage: 0V to 10V
Output accuracy: ±0.1% full scale
Output resolution: 0.01% full scale
Output impedance: < 1Ω
Response time: < 100μs
Power supply voltage: 24V DC
Product Specifications:
Dimensions: Refer to the specification sheet provided by the manufacturer for specific dimensions
Weight: Refer to the specification sheet provided by the manufacturer for specific weight
Operating temperature: -40°C to 70°C
Storage temperature: -40°C to 85°C
Humidity: 5% to 95% (non-condensing)
