WESTINGHOUSE 1C31169G02
1C31169G02 is part of the WESTINGHOUSE Ovation Distributed Control System (DCS) for controlling relay output signals for external devices. It has 16 channels, each of which can be configured for different relay output types, such as normally open, normally closed, etc. The module is often used in industrial automation, power systems, transportation and other fields.
Product parameters:
Model: 1C31169G02
Brand: WESTINGHOUSE
Series: Ovation
Type: Universal relay output module
Number of channels: 16 channels
Output type: The following types can be configured:
Normally open
Normal close
pulse
Contact capacity: 250V AC/DC, 10A
Driving capacity: <100mA
Response time: <2ms
Power supply voltage: 24V DC
Product Specifications:
Dimensions: Refer to the specification sheet provided by the manufacturer for specific dimensions
Weight: Refer to the specification sheet provided by the manufacturer for specific weight
Operating temperature: -40°C to 70°C
Storage temperature: -40°C to 85°C
Humidity: 5% to 95% (non-condensing)
Protection class: IP65
