TRICONEX 5402
The TRICONEX 5402 Digital Output TriPak is a high-performance digital output module designed to provide reliable digital signal output for safety-critical applications. It uses triple redundancy (TMR) technology to ensure reliable digital signal output even if a single channel fails. The module supports 32 digital output channels and has the following features:
Meets SIL 2 and IEC 61508 standards
TMR technology ensures data integrity
Fast response time (1ms)
High output accuracy (±0.1% full scale)
Supports multiple output types (single-ended, differential)
High output impedance (2 kΩ)
Excellent anti-noise performance (-90 dB@0-60 Hz, -100 dB@DC, -3 dB@8 Hz)
Product parameters:
Parameter value
Module type TMR (triple redundancy), digital output
Number of output channels 32
Output type single-ended, differential
Output accuracy ±0.1% full scale
Output impedance 2 kΩ
Response time 1 ms
Power supply voltage 24 VDC
Power consumption 10 W
Operating temperature range -40°C to 70°C
Humidity range 5% to 95% non-condensing
Protection level IP67
Dimensions 233.4mm x 88.9mm x 31.8mm
Weight 1.59 kg
