TRICONEX 3805H
The TRICONEX 3805H is a modular redundancy main processor module that is part of the TRICONEX Invensys Triple modular re
dundancy main processor. This module has the advantages of high reliability, high availability, high maintainability and high security, and is mainly used in petroleum, chemical, electric power, steel and other fields. The TRICONEX 3805H is also a nuclear power specific analog output module, designed for nuclear power plants as a safety instrumentation system in accordance with IEEE and IAEA standards. It is responsible for converting digital signals into analog signals to drive actuators or other devices that require analog input 2.
Product parameters:
Output current range: 4-20 mA (output +6% overrange)
Resolution: 12 bits
Output accuracy: <0.25% of FSR (0-21.2 mA) (in the range of 4-20 mA)
Operating temperature range: from 32° to 140° F (0° to 60° C)
Integral: 8 output current loop, DC coupling
Type: TMR, AO
Specifications:
Brand: Triconex
Number: 3805H
Origin: Zhengzhou, Henan 3
Color: Black 23
Weight: 2.6kg34
Bom number: 380505660313
Output frequency: 50/6023
System environment: room temperature 3
System capability: Smart 3
Operating system: PLC System 4
System function: Programmable 3
