TRICONEX 3805E
The TRICONEX 3805E is a high-performance analog output module designed to provide reliable and accurate analog signal output for safety-critical applications. It uses triple redundancy (TMR) technology to ensure reliable analog signal output even if a single channel fails. The module supports 4 analog current or voltage output channels and has the following features:
Meets SIL 2 and IEC 61508 standards
TMR technology ensures data integrity
Fast response time (2ms)
High output accuracy (±0.1% full scale)
Supports multiple output ranges (-10 V to +10 V, 0 mA to 20 mA, 4 mA to 20 mA)
High output impedance (2 kΩ)
Excellent anti-noise performance (-90 dB@0-60 Hz, -100 dB@DC, -3 dB@8 Hz)
Product parameters:
Parameter value
Module type TMR (triple redundancy), analog output
Number of channels 4
Output Type Current or voltage
Output range -10 V to +10 V, 0 mA to 20 mA, 4 mA to 20 mA
Output accuracy ±0.1% full scale
Output impedance 2 kΩ
Response time 2 milliseconds
Power supply voltage 24 VDC
Power consumption 10 W
Operating temperature range -40°C to 70°C
Humidity range 5% to 95% non-condensing
Protection level IP67
