TRICONEX 3636R
Product Description:
The TRICONEX 3636R module is an enhanced intelligent communication module with a non-isolated CPU module design. Due to its low on-voltage, the module has an inherently low conduction loss, especially in IGCT applications where the on-loss is about 1
.8 to 2.2V, compared to 2.8 to 3.5V12 for IGBTs with comparable voltage ratings. In addition, the TRICONEX 3636R module has been shown through practical use and research tests that its internal IGCT components do not age and have excellent stability and durability.
Product parameters:
On-voltage: For IGCT, about 1.8 to 2.2V; For IGBTs, this is about 2.8 to 3.5V12.
Switching loss: In the case of the latest IGBTs, switching loss is equivalent to or slightly reduced, depending on the specific switching frequency of the application 2.
Specifications:
Rated voltage: CPU module 12 with comparable rated voltage.
Current load: In some applications, the maximum current load can reach 2A3.
Voltage range: 125 VAC/VDC3.
