TRICONEX 3625C1
The TRICONEX 3625C1 module is a key component in the Triconex Safety Instrumentation System (SIS) and is primarily used for digital output. It is able to convert the digital signal from the control system into the actual physical output to control the field equipment and ensure the safety of the industrial process.
Product name resolution
TRICONEX: The brand of modules, a Schneider Electric brand
specializing in safety instrumentation systems (SIS).
3625: Module series, representing that the module belongs to the 3625 series digital output module.
C1: indicates the module model, which represents the specifications and functions of the module.
Product description
The TRICONEX 3625C1 module has the following features:
Digital output: Converts a digital signal into a relay output or a transistor output to drive a field device.
Redundant design: The redundant design improves the reliability of the system. Even if one channel fails, the system can still run normally.
Security functions: With a variety of security functions, such as output voting, diagnostic functions, etc., to ensure the safety of the system.
Flexible configuration: Flexible configuration can be performed based on different application requirements, such as output type and fault response.
Product parameters and specifications (partial, detailed parameters please refer to Schneider Electric official materials)
Parameter Name Parameter Value (Example) Description
Model 3625C1 Product ID
Manufacturer of brand TRICONEX
Type Digital Output module Product category
Output Type Relay output, transistor output type of the output signal
Number of channels Indicates the number of output channels of the module, such as 4 channels and 8 channels
