TRICONEX 3101
Information about the TRICONEX 3101 module is as follows:
Product name: TRICONEX 3101 processor module
Product Description:
The TRICONEX 3101 is a processor module commonly used in industrial control systems. Its main tasks are the execution of control logic, monitoring of industrial processes, data acquisition and communication. As a key component of the TRICONEX control system, it ensures the reliability and safety of industrial processes12. This module uses a high-speed processor and optimization algorithm, which enables it to respond quickly and perform various control logic and data processing tasks, thus improving the stability and response speed of the system. At the same time, it is designed with redundancy and fault tolerance in mind, and can
operate stably in harsh industrial environments, reducing the need for failure and maintenance 1.
Product parameters and specifications:
Application processor: Use Motorola MPC 860, 32-bit, 50 mhz3.
FLASH PROM: 6MB for sx, ix and control application storage with crc protection 3.
DRAM: 16 MB for SX control applications and programs as well as SOE data with byte parity 3.
NVRAM: 8KB, for holding variables, with crc protection 3.
I/O processor: Also using Motorola MPC 860, 32-bit, 50 mhz, DRAM 16 MB for IOX execution, with byte check 3.
Shared memory: 128 KB for Byte parity communication with SX 3.
Diagnostic bus: 2 Mbps HDLC for communication between MP channels and I/O module diagnostic information 3.
Logic power input voltage: 24V DC 3.
Operating voltage range: 24V DC -15%/+20%+5% AC ripple (+19.2/+30V DC)3.
Logic power: Max. 8W3.
