SCHNEIDER K1H004ULHC
The Schneider Electric K1H004ULHC is part of the Compact NSX family of moulded case circuit breakers and is a modular protection device for low-voltage distribution systems. It has the function of overload and short circuit protection, which can reliably protect the circuit and prevent accidents.
Main function
Overload protection: When the circuit current exceeds the rated value for a long time, the circuit breaker will automatically cut off the power to prevent the equipment from overheating and damage.
Short circuit protection: When a short circuit occurs in the circuit, the circuit breaker will quickly cut off the power supply and protect the circuit and equipment.
Leakage protection: Some models have leakage protection function to prevent electric shock accidents.
Undervoltage protection: Some models have undervoltage protection to prevent equipment damage when the voltage is too low.
Product parameters and specifications (for some parameters, please refer to the product manual)
Number of poles: 3P (three-phase)
Rated current: 40A
Rated voltage: 400V
Disconnect capability: Depends on the model
Mounting method: DIN rail mounting
Auxiliary contact: optional
Alarm contact: optional
specification
Model: K1H004ULHC
Manufacturer: Schneider Electric
Number of poles: 3P
Rated current: 40A
Rated voltage: 400V
