SCHNEIDER BMXCPS4002S
The Schneider Electric BMXCPS4002S module is part of the Modicon M340 series of programmable controllers (PLCS). It is a servo drive module for controlling 2-axis servo motors. The BMXCPS4002S module has the following features:
High performance: Pulse frequencies up to 200 kHz are supported for high precision motor control.
High reliability: The use of advanced control technology to ensure the stability and reliability of motor operation.
Easy to use: Support a variety of control modes to meet different application requirements.
Product parameters:
Parameter value
Number of axes 2 axes
Power supply voltage 380 V AC three-phase
Output current 4 A continuous, 6 A peak
Rated power 1.5kW per shaft
Control mode Speed control, position control, torque control, etc
Pulse frequency up to 200 kHz
Positioning accuracy ±0.1°
Overload capacity 150% in 15 seconds
Ambient temperature -10°C to 50°C
Protection class IP20
Dimensions 310 mm x 185 mm x 80 mm
Weight 5.5kg
