SCHNEIDER BMEH582040S
The Schneider Electric BMEH582040S module is part of the Modicon M340 series of programmable controllers (PLCS). It is a driver used to control a three-phase AC servo motor. The BMEH582040S module has the following features:
High performance: Pulse frequencies up to 200 kHz are supported for high precision motor control.
High reliability: The use of advanced control technology to ensure the stability and reliability of motor operation.
Easy to use: Support a variety of control modes to meet different application requirements.
Product parameters:
Parameter value
Power supply voltage 380 V AC three-phase
Output current 40 A continuous, 60 A peak
Rated power 15 kW
Control mode Speed control, position control, torque control, etc
Pulse frequency up to 200 kHz
Positioning accuracy ±0.1°
Overload capacity 150% in 15 seconds
Ambient temperature -10°C to 50°C
Protection class IP20
Dimensions 310 mm x 185 mm x 80 mm
Weight 5.5kg
drive_spreadsheet
Export to Google Forms
Specifications:
Type: Three-phase AC servo motor driver
Control mode: Pulse width modulation (PWM)
Overcurrent protection: current limiting, voltage limiting protection
