SCHNEIDER 140XBP01600
The Schneider Electric 140XBP01600 is a backplane module for the Modicon Quantum series PLC. It provides a robust base for the PLC system to install and connect various I/O modules, communication modules and other functional modules. This backplane is like a chassis that brings together the various components of the PLC system so that it can operate properly.
Main function
Module installation: 16 slots are provided for the installation of various Modicon Quantum series modules, including input/output modules, communication modules, etc.
Signal transmission: Transmit signals between modules to ensure the normal communication of the entire PLC system.
Power distribution: Provides power for the modules installed on the backplane.
System Integration: The individual components of a PLC system are integr
ated into a compact framework.
Product parameters and specifications (please refer to the official documents for specific parameters)
Model: 140XBP01600
Type: Midplane module
Number of slots: 16
Mounting method: DIN rail mounting
Size: 26.4 x 11.4 inches (please refer to the official documentation for details)
Material: Metal, with good electrical conductivity and mechanical strength
