SCHNEIDER 140NOE77101The Schneider Electric 140NOE77101 module is an Ethernet communication module designed for the Modicon Quantum series PLC. It implements communication between PLC and other devices (such as computers, Hmis, other PLCS, etc.) through Ethernet TCP/IP protocol. This module is widely used in industrial automation system to build efficient and flexible network communication system.
Main functions:
Ethernet communication: Provides high-speed and reliable Ethernet communication, supporting a variety of network protocols.
Modbus TCP: Supports the Modbus TCP protocol to facilitate communication with other Modbus devices.
Web Server: Built-in Web server that allows access to module status and configuration through a browser.
SNMP: Supports SNMP, facilitating network management.
Transparent readiness concept: Implements the transparent readiness concept and simplifies network configuration.
Product parameters and specifications (please refer to the product data sheet for specific parameters) :
Model: 140NOE77101
Type: Ethernet network module
Interface: Modicon Quantum bus
Protocol: TCP/IP, Modbus TCP, SNMP
Functions: Network communication, Web Server, SNMP
Port: 1 RJ45 Ethernet port
Application field:
Distributed control system: multiple PLCS are connected into a network to achieve distributed control.
SCADA system: PLC is connected to SCADA system for remote monitoring and control.
Data acquisition: Data is collected from the field device and transmitted to the host computer.
