SCHNEIDER 140CRA93200
The Schneider 140CRA93200 is a remote I/O head dual-channel module in the Modicon Quantum family manufactured by Schneider Electric. The module is designed to be installed on the same backplane as the control CPU module for bidirectional data transfer between the P
CU and RIO drop modules on two different backplanes. It supports Quantum 200 series, 500 Series, 800 series or SY/MAX (any combination) for the remote input/out
put needs of industrial automation and control systems1.
Product parameter
Power consumption: Typical power consumption is 3W, and some data indicate that it is 3.8W123
Bus current: 750mA bus current 13 is required
Ports/branches: With 2 ports/branches, up to 32 ports (16 branches) can be supported 1
Input/output capacity: 64 in words/drops and 64 out words/drops 1
LED indicators: Use 4 LED indicators, including Ready, communication, Error A, and error B1
Transmission rate: The cable type is 75 ohm and the transmission rate is 1544Mbit/s23
Isolation voltage: 500V DC, coaxial center and ground 23
specification
Electrical connection: 2-hole terminal F curved with redundant cable 23
Dynamic range: 35dB45
Antistatic discharge: 4kV according to IEC 801-2 (some sources also indicate 8kV) 45
Anti-electromagnetic domain: 10V/m in accordance with IEC 801-3, frequency range 80… 1000MHz23
Operating temperature: 0… 60°C23
Storage ambient temperature: -40… 85°C23
Relative humidity: 95% non-condensing 45
Working altitude: ≤5000m23
Other characteristics
Compatibility: Seamless integration with Quantum series PLC systems to provide efficient remote I/O scale-out 1
Modular design: easy to install and maintain, flexible configuration according to system requirements1
