WOODWARD 9907-164

The Woodward 9907-164 module is a digital microprocessor controller module for industrial control applications, especially steam turbine control systems. As the core component of the control system, it is responsible for receiving input signals, performing complex calculations and logic processing, and generating output signals to control devices.

Product description

Function: The 9907-164 module is used to control the speed, pressure and other parameters of the steam turbine to achieve accurate control of the entire system.
Application: Mainly used in electric power, petrochemical and other industries, used to control steam turbine generator set.
Features: High reliability, high precision, programmable, easy to maintain.
Product parameters (partial parameters, please refer to the detailed parameters of the product data manual)
Model: 9907-164
Manufacturer: Woodward
Type: Digital microprocessor controller module
Input signal: 4-20mA current signal, voltage signal, digital signal, etc
Output signal: control signal, alarm signal, etc
Operating temperature: -20℃ ~ +60℃
Product picture
Working principle
The 9907-164 module converts these analog signals into digital signals by receiving input signals from sensors and transmitters, such as pressure, temperature, flow, etc., and then performs complex calculations and logical processing. According to the preset control algorithm, the module generates the corresponding output signal to control the action of the actuator (such as valve, regulator), thus achieving precise control of the steam turbine.
