WOODWARD 9907-028

Woodward 9907-028 is a module specifically designed for use with synchronous generators. By precisely matching the speed and phase Angle of the generator, it ensures that the generator can be safely and smoothly connected to the grid or other generator sets. The module plays a vital role in the power generation system to ensure the stable operation of the system.

Main function

Speed and phase matching: precisely match the generator speed and phase Angle to ensure synchronous parallel.
Frequency adaptability: Supports two frequencies of 50Hz and 60Hz to adapt to different power grid environments.
Phase Angle tolerance: a certain phase Angle difference is allowed to improve the flexibility of the system.
Signal processing: Signals from the generator and the grid are processed to ensure the accuracy of the synchronization process.
Product parameters and specifications (typical values, refer to the product data manual)

Voltage input: Support high voltage input, suitable for various generators.
Frequency: 50Hz and 60Hz.
Phase Angle difference: The maximum phase Angle difference allowed.
Output signal: Synchronization signal is provided to control the parallel operation of the generator.
Working environment: Suitable for industrial environment, with high reliability.
