VE4003S2B6 KJ3223X1-BA1

The VE4003S2B6 KJ3223X1-BA1 module is an analog input card in the Emerson DeltaV family. It is mainly used in industrial automation systems, responsible for converting analog signals from the field (such as temperature, pressure, flow, etc.) into digital signals for the controller to process and control.

Product name

English: Emerson DeltaV VE4003S2B6 Analog input card
English: Emerson DeltaV VE4003S2B6 Analog Input Card

Product description
This module is usually installed in a DeltaV system, and through the multiple analog input channels it provides, multiple types of analog signals can be acquired simultaneously. These signals are processed by the analog-to-digital conversion (ADC) circuit inside the module and then transmitted to the controller in digital form to provide real-time data support for the operation of the system.

Product parameters and specifications (part)
Number of channels: 16 channels (subject to actual products)
Input type: analog input (please refer to the product specification for specific supported signal types)
Accuracy: High precision (please refer to the product specification for specific accuracy level)
Sampling rate: configurable (please refer to the product specification for specific configurable range)
Isolation: It usually has isolation between channels to improve the anti-interference ability of the system
Power supply: Powered by the DeltaV system
Size: Standard rack module size
Product characteristics
High reliability: Suitable for industrial environment, with high reliability and stability.
High precision: provides high precision analog signal acquisition to meet the requirements of high measurement accuracy applications.
Multi-channel: supports simultaneous acquisition of multiple analog signals to improve the efficiency of the system.
Configurability: Through software configuration, various parameters of the module can be flexibly adjusted.
Application field
Process control: It is widely used in the process control system of chemical, petroleum, electric power and other industries.
Data acquisition: Used to collect analog signals from various industrial sites for data monitoring and analysis.
Automation system: As an important part of the automation system, it provides reliable analog signal acquisition function.
