TRICONEX 3617E

The TRICONEX 3617E is a high-performance digital output module for the Triconex safety control system. It converts the digital signal of the control system into a relay signal that can be recognized by the field equipment. The TRICONEX 3617E module has the following features:

High reliability: Redundant design and strict quality control ensure reliable module operation.
High power: Up to 15A output current per channel.
Flexible configuration: Support a variety of relay types to meet the needs of different applications.
Easy maintenance: The module design is compact and easy to install and maintain.
Product parameters:

Number of channels: 32
Output type: Relay
Contact capacity: 15A@30VDC
Contact form: 1SPDT
Isolation: Provides isolation between inputs/outputs to prevent interference.
Response time: <1ms

Power consumption: <10W
Operating temperature: -40°C to 70°C
Storage temperature: -40°C to 85°C
Humidity: 5% to 95% (non-condensing)
Product Specifications:

Dimensions: 233 mm x 233 mm x 64 mm
