TRICONEX 8312

The TRICONEX 8312 module is a redundant I/O backplane for the Triconex Safety Instrumentation System (SIS). It is an important part of the Triconex system and can connect various I/O modules to realize the functions of the system. It has high reliability and security and can be used in a variety of safety-critical applications.

The features of this module include:

3-channel redundancy design ensures system security and reliability

Support a variety of I/O module types, such as analog input/output module, digital input/output module, communication module, etc
High diagnostic coverage allows early detection of faults
Meets the requirements of SIL 2/3 safety level
Product parameter

Parameter value
Module Type Redundant I/O midplane
Support module type analog input/output module, digital input/output module, communication module, etc
Maximum number of modules 16
Communication interface Ethernet, RS-232
Power supply voltage 24 VDC
Power consumption 50 W
Operating temperature range -40°C to +70°C
Storage temperature range -55°C to +85°C
Relative humidity 5% to 95% (non-condensing)
Vibration resistance 2 g (10 Hz to 500 Hz)
Impact resistance 10 g (11 ms)
Dimensions 230 mm x 170 mm x 40 mm
Weight 2 kg
Protection class IP65
