TRICONEX 4351B
The TRICONEX 4351B module is a 2 channel 24 VDC isolated relay output module manufactured by TRICONEX for the ControlLogix 5570 series PLC. The module features high-quality components and advanced design for high reliability and high performance.
Product parameter
Module type: isolated relay output’
Power Supply: 24 VDC
Number of output channels: 2
Output voltage range: 24 VDC
Output current range: 1 A
Isolation: 1000 VRMS
Contact type: normally open, normally closed
Contact life: 1 million times
specification
Dimensions: 96 x 96 x 14.6 mm
Weight: 0.25kg
Application scenario
The TRICONEX 4351B module can be used in a variety of industrial applications, such as:
Machine building
Chemical engineering
metallurgy
electricity
transportation
The module can be used to control various devices such as motors, valves, lights, etc.
Matters needing attention
The output voltage range of the module is 24 VDC. Do not connect signals of other voltages.
The output current of the module is 1 A. Do not connect A load with A current greater than 1 A.
The isolation of the module is 1000 VRMS. Do not connect voltage signals that exceed 1000 VRMS.
