TRICONEX 3805E
The TRICONEX 3805E module is an enhanced analog output module manufactured by Triconex for the Triconex Safety Instrumentation System (SIS). The module can provide eight analog output channels, each with an output range of 0-20mA or 4-20mA.
Product parameter
Module type: analog output module
Application System: Triconex Safety Instrumentation System (SIS)
Number of output channels: 8
Output range: 0-20mA or 4-20mA
Resolution: 12 bits
Accuracy: ±0.1%
Response time: <10ms
Isolation: channel to channel, channel to ground
Fault diagnosis: Supported
specification
Dimensions: 228.6mm x 101.6mm x 38.1mm
Weight: About 0.5kg
Ambient temperature: -40°C to +70°C
Storage temperature: -40°C to +85°C
Protection level: IP20
Electromagnetic compatibility and CE marking: comply with EMC Directive 2004/108/EC
Electromagnetic radiation: EMC test according to EN 61000-6-4
Electromagnetic immunity: EMC test according to EN 61000-6-2
Electrical safety: UL508, IEC/EN 61131-2
Hazard Classification Site: UL/CSA 60079-15
