TRICONEX 3625

The Triconex 3625 module is a key component of the Honeywell Triconex Safety Instrumentation System (SIS). It is primarily used to receive digital signals from Triconex controllers or other devices, and to drive external devices such as relays, valves, etc., into action. The 3625 module plays a key role in the safety instrument system, which guarantees the safe and reliable operation of the system.

Visually speaking, this module is like a “switch”, which controls the on-off of external devices according to the digital signal received, so as to achieve the control and protection of the process.

Main function
Digital signal reception: Receive digital signals from Triconex controllers or other devices.
Output driver: Drives external devices, such as relays, valves, etc.
Fault diagnosis: With the diagnostic function, you can detect the fault of the module itself to improve the reliability of the system.
Product parameters (please refer to official materials for specific parameters)
Number of output channels: varies according to the model
Output type: Usually 24VDC output
Load capacity: The load capacity of each channel is different
Response time: Very short, measured in milliseconds
Power supply voltage: 24VDC
Operating temperature: -20°C to +70°C
