TRICONEX 3533E

The TRICONEX 3533E is a high-performance digital input/output module for the Triconex safety control system. It converts the dry contact signal of the field equipment and the digital signal of the control system in both directions. The TRICONEX 3533E module has the following features:

High reliability: Redundant design and strict quality control ensure reliable module operation.
High sensitivity: Can detect weak dry contact signals.
High power: Up to 10A output current per channel.

Flexible configuration: Supports multiple input/output types to meet the needs of different applications.
Easy maintenance: The module design is compact and easy to install and maintain.
Product parameters:

Number of channels: 32

Input type: dry contact
Output type: Relay
Contact capacity: 10A@30VDC
Contact form: 1SPDT
Isolation: Provides isolation between inputs/outputs to prevent interference.
Response time: <1ms
Power consumption: <10W
Operating temperature: -40°C to 70°C
Storage temperature: -40°C to 85°C
Humidity: 5% to 95% (non-condensing)
Product Specifications:

Dimensions: 233 mm x 233 mm x 64 mm
Weight: About 3.5 kg
