SIEMENS 6SE7031-2HF84-1BG0

Product name: SIEMENS 6SE7031-2HF84-1BG0 module

Description: SIEMENS 6SE7031-2HF84-1BG0 module is a frequency converter interface module for industrial control systems produced by SIEMENS. It has an analog input channel for receiving the output current signal of the inverter.

Product parameters:

Number of channels: one
Measurement range for each channel: 0 to 10 V
Power Supply: 24 V DC
Dimensions: 72 x 96 mm
Specifications:

Operating temperature: -40 ℃ to 70 ℃
Storage temperature: -40 ℃ to 85 ℃
Relative humidity: 5% to 95% (no condensation)
Vibration: 20 G rms, 10-50 Hz
Impact: 50 G, 11 ms
Applications:

SIEMENS 6SE7031-2HF84-1BG0 modules can be used in a variety of industrial applications, including:

Process control: used to monitor and control the operating status of the inverter.
Mechanical control: used to control various mechanical equipment.
Data acquisition: used to collect and store the operating data of the inverter.
Specific functions:

An analog input channel: used to receive the output current signal of the frequency converter.
High accuracy: The module has an accuracy of up to 0.05%.
The SIEMENS 6SE7031-2HF84-1BG0 module is a powerful module that can be used in a variety of industrial applications.

Specific function description:

Analog input channel: can measure analog signals from 0 to 10 V.
A picture of the simulated input channel opens in a new window
www.taobao.com
Analog input channel
Output current signal description:

The output current signal of the inverter is usually 0 to 20 mA or 4 to 20 mA current signal. The SIEMENS 6SE7031-2HF84-1BG0 module converts these current signals into analog signals of 0 to 10 V for communication with a PLC or other controller.
