PROSOFT MV156E-MCMR

PROSOFT MV156E-MCMR module
Product name

English: PROSOFT MV156E-MCMR module
English: PROSOFT MV156E-MCMR Module
Product description
The PROSOFT MV156E-MCMR module is the Modbus RTU/TCP master station communication module of the PROSOFT MV156E series modules. The module can be used to connect various Modbus devices to realize data acquisition and control.

Product parameter

Protocol: Modbus RTU/TCP
Primary station/Secondary station: primary station
Number of channels: 1
Baud rate:
Modbus RTU: 115200, 57600, 38400, 19200, 9600, 4800, 2400, 1200
Modbus TCP: 10/100 Mbps
Data bit: 7 or 8
Stop bit: 1 or 2
Parity check: None, even, or even
Indicator light:
Communication status light
Module power indicator
specification
Size: 8HP
Power Supply: 24 Vdc
Power consumption: 2 W
Ambient temperature: 0 to 60 °C
Humidity: 5% to 95% (non-condensing)
