PROSOFT MVI56E-MCMR
The PROSOFT MVI56E-MCMR module is a Modbus master/slave communication module produced by PROSOFT for the ControlLogix series PLC with the following features:
Support Modbus RTU/ASCII protocol
2 separate serial ports
Supports multiple data formats
Easy to install and use
Product parameter
Parameter value
Module Type Communication module
Supported protocol Modbus RTU/ASCII
Two serial ports
Baud rate 115200, 57600, 38400, 19200, 9600, 4800, 2400, 1200
Data bits 7, 8
Stop bits 1 and 2
Parity Check None, parity, or even
Communication mode EtherNet/IP
Power supply 24V DC
Mounting method DIN rail mounting
Dimensions 96 x 96 x 48 mm
Weight 200g
