PR0S0FT PTQ-PDPMV1

Profit PTQ-PDPMV1 module is a protocol conversion module produced by Profit for connecting Profibus DP master station and Modbus TCP/IP slave station. It can convert Profibus DP protocol to Modbus TCP/IP protocol, and supports a variety of data types and functional codes, which can meet the needs of various industrial control applications.

Application field:

Profit PTQ-PDPMV1 modules are widely used in industrial automation fields, such as metallurgy, chemical, textile, paper, food and beverage industries.

Product features:

Profibus DP V1.0 and V2.0 protocols are supported

Supports Modbus TCP/IP
Multiple data types and functional codes are supported
Programmability, allowing users to customize and write control logic as needed
Condition monitoring and fault diagnosis function, which is used to monitor the working status of the module in real time and find problems in time
Product parameter

Parameter value
Model PTQ-PDPMV1
Number of channels 1
Master protocol Profibus DP
Slave station protocol Modbus TCP/IP
Baud rate 9.6Kbps to 12Mbps
Data type BOOL, BYTE, WORD, and DWORD
Function codes 01, 02, 03, 04, 05, 06, 08, 16, etc
Operating voltage 24VDC
