NI SCXI-1326

The NI SCXI-1326 is a high voltage terminal board designed for National Instruments SCXI systems. It is mainly used to connect the SCXI module to provide high-voltage digital input or digital output interface. The module is usually used with modules such as SCXI-1162, SCXI-1162HV, SCXI-1163, and SCXI-1163R, and is suitable for application scenarios requiring high voltage measurement.

Main function

High voltage connection: provides high voltage digital input or digital output interface.
Module connection: Connected to the SCXI module to achieve signal transmission and conversion.
Shielding design: With shielding design, reduce electromagnetic interference.

Product parameter specification
Maximum voltage: 300V
Number of terminals: 48
Protection class: CAT II
Compatible modules: SCXI-1162, SCXI-1162HV, SCXI-1163, SCXI-1163R
