NI SCXI-1193

The NI SCXI-1193 module is a 32-channel RF multiplexer switch module for the SCXI series of modular signal conditioning systems manufactured by National Instruments for routing multiple RF signals to one or more output channels. The module features high density, high performance and ease of use, making it suitable for various RF test and measurement applications.

Product parameters:

Number of channels: 32

Frequency range: DC-500MHz
Insertion loss: <1dB
Isolation: >20dB
VSWR: <1.5:1
Maximum input power: +20dBm
Supply voltage: ±15V
Power consumption: 5W
Operating temperature: 0-55°C
Storage temperature: -40-70°C
Dimensions: 176 x 64 x 40 mm
Weight: 0.25kg
