NI SCXI-1193

The NI SCXI-1193 is a high-performance, highly reliable 10-channel analog input module for converting analog signals to digital signals. The module uses A high precision A/D converter to provide high precision and high resolution measurement results. The module has the following features:

High precision: High precision A/D converter, measuring accuracy up to ± 0.025%FS.

High resolution: Resolution up to 24 bits, providing fine measurement results.
Wide range: Wide measuring range, -10V to +10V.
Fast sampling rate: Sampling rate up to 250 kS/s, able to capture rapidly changing signals.
Multiple trigger modes: Supports multiple trigger modes, including external trigger, software trigger, and timed trigger.
Easy to use: Simple to operate and easy to use.
Strong compatibility: Compatible with NI LabVIEW, NI LabVIEW FPGA and other software platforms.
Product parameters:

Parameter value
Number of channels 10
Measuring accuracy ± 0.025%FS
Resolution 24 bit
Range -10V to +10V
Sample rate 250 kS/s
Input impedance 10 MΩ
Common mode rejection ratio (CMRR) >120 dB
Common mode rejection ratio (CMRR) >120 dB
Operating temperature -40°C to 70°C
Storage temperature -40°C to 85°C
Humidity 5% to 95% RH (non-condensing)
