NI SCXI-1162HV

The NI SCXI-1162HV High voltage analog input module is a high voltage analog input module for PXI/PXIe chassis manufactured by National Instruments. It can provide 8-channel high-voltage analog inputs up to 1000V. The 1162HV module has the following features:

High voltage range: ±1000V
High accuracy: ±0.05% FSR

High sampling rate: up to 250 kS/s
Supports multiple signal types: single-ended, differential

Support synchronous acquisition
The 1162HV module is used in a wide range of high voltage test and measurement applications, including:

High voltage circuit test
Power system testing
Sensor test
Scientific research experiment
Product parameters:

Number of channels: 8
Resolution: 16 bits
Sampling rate: up to 250 kS/s
Input range: ±1000V
Input impedance: 10 MΩ
Power supply: DC 5V
