NI PXI-7344

The NI PXI-7344 module is a high-performance multi-channel digital I/O module manufactured by National Instruments for use in PXIe chassis. The module features 48-channel digital I/O, sampling rates up to 10 MHz, and multiple triggers to meet a wide range of application needs.

Product parameters:

Number of channels: 48
Direction: Input/output
Voltage range: 5V
Sampling rate: 10 MHz
Resolution: 16 bits
Trigger mode: software trigger, hardware trigger, edge trigger, pulse trigger
Size: 3U PXIe module
Weight: 0.5kg
Specifications:

Interface:
PXIe Express x1
Two 50-pin D-Sub connectors
Setting:
Operating temperature: 0°C to 55°C
Storage temperature: -40°C to 70°C
Humidity: 5% to 95% (non-condensing)
Applications:

Industrial automation control system
Test and measurement
Robot
Process control
Manufacturing industry
