NI PXI-7340

Description: The NI PXI-7340 module is a 3-axis motion control module for PXI systems.

Product parameters:

Model: PXI-7340

Number of axes: 3
Pulse output frequency: 20MHz

Position resolution: 0.1μm
Velocity resolution: 0.01μm/s
Acceleration resolution: 0.001μm/s^2
Rated voltage: 24V DC
Power consumption: <5W
Size: 80mm x 45mm x 25mm
Weight: 0.2kg
Product features:

Control 3-axis servo motor
Supports multiple pulse output modes
Provides high precision position, speed and acceleration control
