NI PXI-4472B

Product Description:
The NI PXI-4472B module is a digital multiplexer module powered by the Peripheral Component Interconnect (PXI) bus manufactured by National Instruments (NI). The module integrates multiplexer functions into a compact module for high-performance test and measurement applications.

Product parameters:

Number of channels: 16

Voltage range: ±10V DC
Current range: 0-20mA
Resolution: 16 bits
Operating temperature range: 0-55℃
Sampling rate: up to 250kHz
Trigger mode: edge trigger, slow trigger, etc
Trigger source: internal trigger or external trigger

Input impedance: 1MΩ
Output impedance: 50Ω
Accuracy: ±0.02%
Power requirements: +5V DC, 1A
Specifications:

Size: Standard size, can be customized
Connection mode: Connected to the controller through the PXI bus
Extensibility: Can be used in combination with other PXI modules to expand functionality and channel count.
Environmental adaptability: Suitable for use in laboratory and test environments.
