NI PXI-4065

The NI PXI-4065 module is a high-performance digital multimeter (DMM) module in NI’s PXI system family. The module provides all the usual DMM functions, including DC and AC voltage, DC and AC current, 2 – and 4-wire ground resistance, open circuit, short circuit, capacitance, and temperature measurement.

Product parameter

Measuring range:

Dc voltage: ±300V
Ac voltage: ±300V
Dc current: ±1A
Ac current: ±1A
Resolution: 6½ bits
Maximum sampling rate: 5kS/s
Resistance measurement range: 300Ω to 100MΩ
Capacitance measurement range: 1nF to 1000µF
specification

Size: 3U, single slot PXI module
Operating temperature: 0°C to 55°C
Storage temperature: -40°C to 71°C
Operating humidity: 10% to 90%, no condensation
Storage humidity: 5% to 95%, non-condensing
