NI NI-9505

The National Instruments NI-9505 module is a versatile digital input/output (DIO) module designed for National Instruments’ CompactRIO and Single-Board RIO platforms. The module offers 32 configurable digital I/O channels and four high-speed counter channels for a variety of industrial automation, test and measurem

ent, and embedded system applications. The NI-9505 module combines high performance and flexibility to meet a wide range of complex digital signal processing and control needs.

Product parameters:

Digital input/output channels: The module provides 32 configurable digital I/O channels that support multiple input/output modes such as quasi-bidirectional, drain open, source open, and push-pull outputs.
High-speed counter channels: The NI-9505 module also provides four high-speed counter channels that can be used to measure frequency, period, duty cycle and other parameters.
Communication interface: The module communicates with CompactRIO or Single-Board RIO controller through high-speed RIO bus to realize real-time data transmission and control.
