MTL MTL5546Y

The MTL 5546Y is an isolated drive for industrial automation. It is primarily used to isolate 4/20mA floating signals from safe zone controllers and drive current/pressure converters or other loads inside the danger zone. This isolation design can effectively prevent potential explosion risks in dangerous areas and ensure the safety of equipment and personnel.

Product parameters and specifications:
Model: MTL 5546Y

Function: Isolation driver

Input signal: 4/20mA floating signal
Output signal: 4/20mA
Load capacity: Maximum 800Ω
Isolation voltage: High isolation voltage to ensure safe isolation
Operating temperature: -40℃ to +85℃
Protection level: Different protection levels are provided according to the specific model and configuration
Certification: Compliance with relevant safety standards, such as ATEX, IECEx, etc
Other features:
Fast response time: Fast response to changes in the input signal
High reliability: Designed for harsh industrial environments
Easy installation: Provide a variety of installation methods
The main functions of the MTL5546Y module:
Signal isolation: Isolate signals in safe and dangerous areas to prevent sparks or arcing.
Signal conversion: The 4/20mA signal is converted to drive the load.
Overcurrent protection: has the function of overcurrent protection to protect the equipment.
