MOTOROLA MVME5500
The MOTOROLA MVME5500 module is a high-performance, versatile module designe
d for a wide range of applications. It has the following characteristics:
Powerful PowerPC 7448 processor
Up to 2GB of DDR SDRAM memory
Two 10/100/1000BaseT Ethernet interfaces
Two PMC slots for additional I/O expansion
Multiple operating systems are supported, including VxWorks, Linux, and Windows XP
The MVME5500 module is used in a wide range of industrial applications, including:
Industrial control
Data acquisition
Image processing
communication
Medical treatment
Product parameters:
Processor: PowerPC 7448
Main frequency: 1.3GHz
Memory: Up to 2GB DDR SDRAM
Storage: IDE hard drive or CF card
I/O:
Two RS-232 serial ports
1 parallel port
2 USB 2.0 ports
Network:
Two 10/100/1000BaseT Ethernet ports
Extensions:
Two PMC slots
Power supply: 24VDC
Power consumption: 40W Max
Operating temperature: 0°C to +55°C
Storage temperature: -40°C to +85°C
Protection level: IP30
Specifications:
Dimensions: 230 x 167 x 64 mm
Weight: 1.5kg
