MOOG G122-824-002

The G122-824-002 module is a Moog series servo valve produced by Moog Company, which is used to control the flow and pressure of hydraulic systems. The module has the characteristics of high precision, high response speed and high reliability.

Product parameters:

Flow range: 22 gpm (83 L/min)
Pressure range: 3000 psi (207 bar)
Response speed: 400 Hz

Rated voltage: 28 VDC
Rated current: 2 A
Power: 56 W
Dimensions: 114.3 x 88.9 x 76.2mm
Weight: 2.27 kg
Specifications:

Protection class: IP65
Cooling method: air cooling
Setting:
Operating temperature: -40°C to 85°C
Storage temperature: -55°C to 100°C
Humidity: 5% to 95% (non-condensing)
Applications:

Industrial automation control system
Robot
Process control
Manufacturing industry
Material flow
Advantages:

Stable and reliable
Flexible and easy to use
High performance
expandable
Easy to maintain
