MOOG D138-002-012

Moog D138-002-012 Solenoid valve module is a solenoid valve module for Moog series servo systems. It can control the flow and direction of the hydraulic system, thus controlling the movement of the servo system.

Product parameters:

Model: D138-002-012
Voltage: 24VDC
Power: 10W
Flow rate: 10L/min

Pressure: 20MPa
Operating temperature: 0°C to 60°C
Storage temperature: -40°C to 85°C
Relative humidity: 5% to 95% (non-condensing)
Dimensions: 22.5 x 100 x 45 mm

Weight: 0.25kg
Specifications:

High pressure, high flow
Fast response
Low power consumption
Easy to install
Applications:

Industrial automation
Machine control
aerospace
National defense
Other applications requiring high performance solenoid valves
Related links:

Moog Product page: [Invalid URL removed]
Moog Manual: [Removed invalid URL]
Photos:

D138-002-012: [Invalid URL removed]

Chinese translation:

Product name: Moog D138-002-012 solenoid valve module

Product Description:

Moog D138-002-012 Solenoid valve module is a solenoid valve module for Moog series servo systems. It can control the flow and direction of the hydraulic system, thus controlling the movement of the servo system.

Product parameters:

Model: D138-002-012
Voltage: 24VDC
Power: 10W
Flow rate: 10L/min
Pressure: 20MPa
Operating temperature: 0°C to 60°C
Storage temperature: -40°C to 85°C
Relative humidity: 5% to 95% (non-condensing)
Dimensions: 22.5 x 100 x 45 mm
