mitsubishi HC703BS-E51

The Mitsubishi HC703BS-E51 module is a 32-channel high-speed pulse output module produced by Mitsubishi Electric Corporation for the Q series PLC with the following features:

32 channel high-speed pulse output
Maximum output frequency 200MHz
Supports multiple pulse modes

Easy to use
Product parameter

Parameter value
Module Type High-speed pulse output module

Number of channels 32
Maximum output frequency 200MHz
Pulse mode Timing pulse, pulse column, PWM pulse
Resolution 1ns
Load capacity 30mA
Communication mode EtherNet/IP, CC-Link IE Field
Power supply 24VDC
Mounting method DIN rail mounting
Dimensions 96 x 96 x 48 mm
