IC697MDL750 GE
The GE IC697MDL750 is a 12/24VDC Positive/Negative Logic Input module. It provides 32 inputs (16 groups of 2) with a common power input terminal (15-48VDC). Each input can be individually wired as a positive or negative logic input.
This module is designed for use with the GE Series 90-70 PLC system. It is compatible with the IC697BEM731 and IC697BEM733 Bus Controllers.
The IC697MDL750 module has a green LED indicator for each input that shows the status of the input. When the input is ON, the LED will be lit. When the input is OFF, the LED will be off.
This module has a maximum power consumption of 2.5 Watts and a maximum heat dissipation of 8.5 BTU/hr. It has a operating temperature range of 0-60 degrees Celsius and a storage temperature range of -40 to 85 degrees Celsius.
The module can be installed in any I/O slot of a Series 90-70 PLC system. It requires a backplane voltage of 5VDC and has a backplane current of 290mA.
In summary, the GE IC697MDL750 is a versatile and reliable input module that provides 32 inputs for use with the GE Series 90-70 PLC system. Its positive/negative logic, LED indicators, and wide temperature range make it an ideal choice for a variety of industrial applications.
GE Fanuc IC600BF946L Loop Management Module IC600BF946K
Westinghouse Panelboard Switch FDP-324R 200 Amp 240V FDP324R Fusible 200A
Fanuc Ltd A06B-6089-H209 AC Servo Amplifier Unit 10A A06B6089H209
Reliance Electric 45C316 19 Slot Rack AutoMax PLC Chassis 802822-14RD 59000-15
Ormec SAC-SM410/S ServoWire Servo Control Axis R-1.0.02 SACSM410
Specifications
- Power supply voltage: 12/24 VDC
- Power supply voltage range: 9.6-30 VDC
- Backplane current load: 0.16 A
- Output voltage range: 5-30 VDC
- Output current per point: 2 A
- Isolation voltage: 1500 VDC
- Output points: 32
