IC693ALG442 AB
The IC693ALG442 AB is a 4-channel Analog Voltage Output module manufactured by GE Fanuc Automation. It is used in conjunction with GE Fanuc PLC systems to provide analog voltage output signals to control external devices such as motors, valves, and other process control equipment. Each channel of the module can provide an output range of 0-10 volts DC with a resolution of 12 bits.
The IC693ALG442 AB module is designed for use in industrial environments and is built to withstand harsh conditions such as extreme temperatures, humidity, and vibration. It is also equipped with protection features such as overvoltage and overcurrent protection to prevent damage to the module and connected devices.
Installation of the IC693ALG442 AB module is simple and straightforward. It can be easily installed into a GE Fanuc PLC system using the provided mounting hardware and wiring connections. The module is powered directly from the PLC system and does not require an external power source.
In summary, the IC693ALG442 AB module is a reliable and versatile analog output module that can be used in a wide range of industrial applications. Its rugged design and protection features make it a suitable choice for use in harsh environments, while its ease of installation and use make it a popular choice for process control applications.
Parameters
- Input Voltage Range: -10V to +10V
- Resolution: 16 bits
- Input Configuration: Single-ended or differential
- Input Filter Option: Yes
- Custom Input Ranges: Yes
- Isolation: Yes
The AB IC693ALG442 has the following product information:
- Manufacturer: GE Fanuc Automation
- Product Type: Analog Output Module
- Model Number: IC693ALG442
- Input Voltage: 24VDC
- Output Voltage Range: 0-10VDC
- Output Current: 0-20mA or 4-20mA
- Number of Channels: 4
