IC670GBI002 GE
The GE IC670GBI002 is a Genius I/O Block that provides an interface between a Series 90-70 PLC and a remote I/O device. It is part of the GE Genius I/O system and is used to connect the PLC to a variety of input and output devices, including switches, sensors, actuators, relays, and solenoids.
The IC670GBI002 supports up to 32 I/O points and can be configured for either discrete or analog I/O. It features a rugged, compact design and is designed for use in harsh industrial environments.
The I/O block communicates with the PLC over a Genius bus, which allows for fast, reliable data transfer. It supports a variety of communication protocols, including Profibus-DP, DeviceNet, and Modbus.
In addition to its I/O capabilities, the IC670GBI002 also features built-in diagnostics and fault detection, allowing for easy troubleshooting and maintenance. It also supports hot-swapping, which means that it can be replaced without shutting down the entire system.
Overall, the GE IC670GBI002 is a versatile and reliable I/O block that is ideal for use in a wide range of industrial applications.
The module has the following parameters:
- Module Type: IC670GBI002
- Power Supply Voltage: 18 to 32 Vdc
- Power Consumption: 3 W maximum
- Operating Temperature: -40°C to +70°C
- Storage Temperature: -40°C to +85°C
- Humidity Range: 5% to 95% non-condensing
- Dimensions (HxWxD): 4.4 x 12.7 x 14.2 cm
- Weight: 0.34 kg
The following parameters can be configured for the GE IC670GBI002 module:
- Input type: The module supports a range of input types, including AC/DC voltage, AC/DC current, and resistance.
- Filter time: This parameter sets the time constant for input filtering. It can be set to a value between 0.1 and 32 milliseconds.
- Input range: This parameter sets the input voltage or current range. It can be set to a range between 0 and 5 volts, or between 0 and 20 milliamps.
- Input bias: This parameter sets the bias current for the input circuit. It can be set to a value between 0 and 50 microamps.
