GE PCIE-5565RC-100000

The GE PCI-5565RC-100000 module is a 10-channel analog input module with a PCIe interface from GE, designed for Proficy Machine Edition software and the PACSystems RX3i series programmable logic controllers (PLCS). The module can be used to convert analog voltage or current signals from field equipment into digital signals and pass them to the PLC for data acquisition and control.

The GE PCI-5565RC-100000 module has the following features:

10 channels: 10 analog signals can be collected simultaneously
Supports multiple signal types: voltage, current
Wide range: can meet different application requirements
High accuracy: Ensure the accuracy of data acquisition
Programmable filter: eliminates high frequency noise

Fault indication: Indicates module failure
Product parameter
Parameter value
Number of channels 10
Input signal type Voltage, current

Input voltage range ±10 V, ±50 V, ±100 V
Input current range ±20 mA, ±100 mA
Resolution 16 bit
Sample rate 256 kS/s
Filter programmable
Power supply 24 VDC
