GE IC697CPX935

The GE IC697CPX935 is an intelligent relay module for a variety of industrial applications, including motor control, heating control and lighting control. The module has the following features:

1 25A AC output relay
Programmable delay time and pulse width
LED indicator

Photoisolated input
DIN rail mounting

Product parameters:

Rated voltage: 24V DC or 24V AC
Rated current: 25A
Output type: Relay
Input type: photoelectric isolation
Delay time: Programmable, 0.1 to 100 seconds
Pulse width: Programmable, 0.1 to 100 seconds
Operating temperature: -40°C to 70°C
Storage temperature: -40°C to 85°C
Humidity: 5% to 95% (non-condensing)
Dimensions: 35mm x 75mm x 22mm
Specifications:

Certification: UL, CE, CSA
Protection level: IP67
Applications:

Motor control
Heating control
Lighting control
Valve control
