GE IC693MDL740

GE IC693MDL740 module

Product name: GE IC693MDL740 Digital input/output module

Product Description:

The GE IC693MDL740 is a Programmable logic controller (PLC) module 2 in the 90-30 series. This module is a positive logic output module, mainly used to provide current to connected loads, such as contactors, relays, indicators, buzzers, horns and other common electrical loads1. The module has sixteen (16) source outputs, divided into two sets of eight channels each, each with a capacity of 0.5 ampers1. The module also has a front panel LED indicator located at the top, representing the startup status of each module channel and the operating status1 of the module.

Product parameters:

Output points: 16

Output type: positive logical output
Output capacity: 0.5 amps per channel
Operating voltage range: 12 to 24 volts DC (20%, -15%)
Output voltage range: 12 to 24 volts DC
Response time: ON response time is 2ms, Off response time is up to 2ms
Maximum inrush current: Rated inrush current of 4.78 amps for 10 milliseconds
Power consumption: 110 mA (all outputs are on)
Specifications:

Mount: Mount on any available slot of the 5-slot or 10-slot series 90-30 substrate 1
Protection: External fuses can be installed to further protect module 1
Compatibility: Compatible with multiple load devices, including solenoid valves and motor starters 1
