GE 469-P5-HI-A20-E

The GE 469-P5-HI-A20-E module is a motor protection relay manufactured by General Electric (GE) in the Multilin 469 series. It is mainly used to monitor, control and protect medium and large motor to ensure the safe operation of the motor.、

Product description

The 469-P5-HI-A20-E module is equipped with advanced protection functions to detect various faults that may occur in the motor, such as overload, short circuit, ground fault, stall, etc. The module also has rich control functions, which can realize the operation of motor starting, stopping, accelerating, decelerating and so on.

Product parameters and specifications (part, specific parameters please refer to GE official materials)
Parameter Name Parameter Value Description
Model 469-P5-HI-A20-E Product identification
Brand GE Manufacturers
Type Motor protection relay Product category
Current Class 5A Rated current of the secondary side of the phase current transformer
Protection function Overload, short circuit, ground fault, stall and other main protection functions
Communication interface [Specific interface] Used to communicate with the host computer
Mounting method DIN rail mounting method

Main function
Motor protection: provides a variety of protection functions to ensure the safe operation of the motor.
Motor control: to achieve motor start, stop, acceleration, deceleration and other operations.
Data monitoring: monitoring the operating parameters of the motor, such as current, voltage, frequency, etc
